DOUBLE SIDED PE FOAM TAPE (1mm THICKNESS) (5)
https://www.atyt.es/shop/double-sided-pe-foam-tape-1mm-thickness-5-1474 https://www.atyt.es/web/image/product.template/1474/image_1920?unique=91ab007| Thickness: 1 mm |
| Packaging type: Bulk |
Share:
Composition
Liner (A): Film HDPE
Adhesive type (B): Solvent acrylic
Support (C): PE FOAM
Adhesive type (D): Solvent acrylic
Characteristiques
High level permanent fixing on a wide variety of materials.
Good hermetic sealing capacity.
Very good shock absorption in cold weather.
High level of adhesion on the vast majority of surfaces.
Excellent weather resistance (UV rays, solvents, humidity).
Applications
Recommended use on surfaces such as wood, metals, glass and even materials with rough surfaces.
Sealing of joints in air ducts. Moisture barrier.
Sealing of boiler containers as well as high pressure steam pipes.
Identificación cuando se requiere revisión por aparatos fotoeléctricos.
Certifications
In the "Documents" tab you will find the certifications available for our product.
If you need any other type of certification to apply the product in your field, please contact us.
Discover more
Usual Presentation
Please go to the specific tab within the product page.
Any other width and length available upon request. We offer the possiblity of customising the core or packaging of the product you wish.
Please consult with us about the various customisation options and how we can help you.
Contact Us
Related Products
STORAGE CONDITIONS
For better preservation of its properties, the product should be stored in its original packaging at a temperature between 20 and 30ºC, protected from direct sunlight and moisture. It is recommended to use the product within 24 months after receipt.
GENERAL WARRANTY CONDITIONS
ATyT recommends that the contact surfaces be clean of grease, oil, dust or any other non-stick substance.
The technical data contained in this product specification is intended to guide the end user and does not imply a legal guarantee regarding certain properties, due to the numerous influences that may occur during the handling and use of the product.
Before use, the consumer must evaluate the suitability of the product for its specific purpose and will assume all risk and responsibility in relation to such use.
| ADHESIVE PROPERTIES | VALUES | METHOD |
|---|---|---|
| Liner thickness | 0.075 mm | INTERNE |
| Total thickness | 1 mm | INTERNE |
| Density | 55 kg/m3 | INTERNE |
| Adhesion to steel | 8 N/cm | ASTM D-3330 |
| Static shear strength | ≥ 10 h | ASTM D-3654 |
| Rolling Tack Ball | ≤ 5 cm | ASTM D-3121 |
| Service temperature range | [-20ºC - +70ºC] | INTERNE |
A: Outside diameter (mm)
B: Inner diameter (mm)
C: Width (mm)
D: Length (m)
| A | 265 mm | 300 mm | ||
| B | 76 mm | |||
| C | 9,12,15 mm | 19, 25, 50 mm | ||
| D | 50 m | 66 m | ||
Composition
Liner (A): Film HDPE
Adhesive type (B): Solvent acrylic
Support (C): PE FOAM
Adhesive type (D): Solvent acrylic
Characteristiques
High level permanent fixing on a wide variety of materials.
Good hermetic sealing capacity.
Very good shock absorption in cold weather.
High level of adhesion on the vast majority of surfaces.
Excellent weather resistance (UV rays, solvents, humidity).
Applications
Recommended use on surfaces such as wood, metals, glass and even materials with rough surfaces.
Sealing of joints in air ducts. Moisture barrier.
Sealing of boiler containers as well as high pressure steam pipes.
Identificación cuando se requiere revisión por aparatos fotoeléctricos.
Certifications
In the "Documents" tab you will find the certifications available for our product.
If you need any other type of certification to apply the product in your field, please contact us.
Discover more
Usual Presentation
Please go to the specific tab within the product page.
Any other width and length available upon request. We offer the possiblity of customising the core or packaging of the product you wish.
Please consult with us about the various customisation options and how we can help you.
Contact Us
Related Products
